7ZDGS-250

Technical Specifications	Unit	Model
Technical Specifications	Unit	7ZDGS-250
Driving Form	/	Self-Propelled
Structural Form	/	Monorail, Bidirection
Matching Power Type	/	DC Generator
Rated voltage of the supporting power supply	/	60v
Rated power of the supporting power supply	kW	2.5
Rated rotational speed of the supporting power supply	r/min	3300
Engine Capacity	mL	/
Fuel Tank Capacity	L	/
Oil Level	L	/
The amount of oil injected into the gearbox	L	2.5
Type of Battery	/	Lithium Ion Battery
Battery Capacity	A•h	60
Overall Machine Weight	kg	200
Rated Loading Capacity	kg	250
Maximum Slope Gradient	(°)	45
Dimensions of the Trolley (length×width×height)	mm	1950×560×700
Rail Form	/	Toothed Bar Type
Rail Material Model	/	Q235R2.5-3000
Rail Wall Thickness	mm	Optional:2.5/2.75/3.0
Rail Unit Length	m	3
Operating Speed	m/s	0.8
Size of the Package of the Drive Unit (length×width×height)	cm	88×57×80
Volume of the Package of the Drive Unit	m³	0.402
Weight of the Package of the Drive Unit	kg	15
